The 10 Ton Gantry Crane is a light to medium-duty lifting solution designed for efficient material handling in workshops, warehouses, freight yards and small to medium-sized industrial facilities. It adopts a single or double main beam structure with an electric hoist as the primary lifting mechanism, providing reliable lifting performance and flexible operation.
With a standard lifting height of 3–12 meters and customizable span options, the 10-ton gantry crane uses a trolley travelling system to achieve smooth horizontal movement of loads along the main beam. Its compact structure reduces installation requirements while maintaining stable lifting capacity and convenient operation.
The 10 Ton Gantry Crane is widely used for loading, unloading, transferring and stacking materials up to 10 tons. Due to its simple design, reliable performance and economical operation, it is an ideal material handling solution for logistics, chemical, construction, mining and general industrial applications.
Customized 10 Ton Gantry Crane Solutions
The crane structure and accessories can be customized according to different working conditions, lifting requirements and application environments. Nucleon provides multiple configurations including single girder gantry cranes, double girder gantry cranes, portable gantry cranes, truss gantry cranes and semi-truss gantry cranes.
These flexible configurations allow customers to select suitable lifting solutions according to workspace conditions, material handling requirements and operational frequency.
10 Ton Single Girder Gantry Crane
The single girder 10-ton gantry crane features a simple structure, lightweight design and convenient installation. Compared with double girder models, it requires lower investment and provides easier relocation when working conditions change.
The crane adopts an electric hoist as the main lifting device. The hoist travels along the lower flange of the main beam to complete vertical lifting and horizontal transportation of materials, ensuring efficient and stable handling operations.
Flexible Electric Hoist Options
According to different operating requirements, the 10-ton gantry crane can be equipped with either wire rope hoists or chain hoists. Users can select the most suitable lifting mechanism based on lifting frequency, working environment and application demands.
Logistics and Warehousing:
Used for loading, unloading, transferring, and stacking goods in warehouses and storage areas.
Manufacturing Industry:
Applied in workshops and production lines for material transportation, component handling, and process connection.
Ports and Terminals:
Suitable for loading, unloading, and short-distance transportation of containers, bulk materials, and heavy cargo.
Construction Industry:
Used for lifting construction materials such as steel bars, precast concrete components, and other building materials.
Simple and Reliable Structure
The single girder gantry crane adopts a box-type or I-beam main structure, featuring lightweight design, good structural rigidity, easy installation and convenient maintenance. The optimized structure provides reliable performance while reducing overall equipment complexity.
Efficient Material Handling Operation
The crane provides smooth and flexible operation, enabling operators to efficiently lift, transport and position materials in different industrial working environments.
Economical and Practical Design
With lower manufacturing costs and simple maintenance requirements, the crane provides a cost-effective lifting solution for small and medium-tonnage material handling applications.
Flexible Electric Hoist Compatibility
The crane supports various electric hoist configurations, including CD, MD and European standard hoists, allowing flexible selection according to lifting capacity, working conditions and operational requirements.
Compact Space-Saving Layout
The single main beam structure reduces installation space requirements and is especially suitable for workshops and industrial facilities with limited building height or restricted working areas.
Nucleon Cranes provides customized 10-ton gantry crane solutions designed for industrial material handling, workshops, warehouses and outdoor lifting applications. Featuring a modular design concept, the 10 ton gantry crane can be configured according to different customer requirements while maintaining excellent structural stability, reliable performance and standardized manufacturing quality.
With flexible customization options, the crane structure, lifting system and control configuration can be adapted to different installation conditions and working environments. Our engineering team evaluates each project requirement to provide an efficient, safe and cost-effective gantry crane solution.
Main Customizable Parameters
Lifting Capacity: Standard lifting capacity is 10 tons, with customized options available according to specific material handling requirements.
Span: Adjustable crane span based on workshop layout, working area and site installation conditions.
Lifting Height: Customizable lifting height to meet different cargo dimensions and operational requirements.
Control Method: Available with pendant control or wireless remote control systems for convenient and flexible operation.
Hoist Type: Compatible with electric wire rope hoists, chain hoists and explosion-proof hoists for different industrial applications.
Working Class: Designed according to FEM/DIN working standards, with working class options from A3 to A5.
Certification Requirements: Available with CE, ISO, EAC and other international certification standards according to project requirements.
For specific project requirements, Nucleon Cranes provides professional technical consultation and customized 10 ton gantry crane configurations based on actual working conditions. Our solutions help customers achieve safe operation, high lifting efficiency and long-term equipment reliability.
| Parameter name | Regular range |
|---|---|
| Rated lifting capacity | 10 tons |
| span | 10-35 meters |
| Lifting height | 6-30 meters |
| Job Level | Level A3- A5 |
| Lifting speed | 0.8-8m/min |
| Car running speed | 10-30m/min |
| Cart running speed | 20-45m/min |
| Power supply mode | Three-phase AC, 380 V, 50 Hz |
